GRAPHTEC FC 4500 Series Service Manual page 172

No. Part No.
36 U622192091 Arm Spring 2
37 U621353010 Thumb Screw L10
U621353020 Thumb Screw L14
38 U772219510 Relay Board,4500
39 U772219520 Mark Sensor Board, 4500
U772121530 Mark Sensor Board, 4510
40 U772219530 Pen Board, 4500
U772121520 Pen Board, 4510
41 U561080005 Encoder, HEDS-9720#P50
42 U792219701 FC4200 Pen Block Assy
U792121701 FC4210 Pen Block Assy
43 U621213001 Y Pre-Tension Plate
44 U622192200 Y Slider
45 U792219702 Pen Holder AP Assy
46 U792219703 Pen Station AP Assy
47 U622190500 Stopper 8MM
48 U621212010 Flexible Cable Guide K
49 U622190211 Flexible Cable Guide B
FC4500-UM-251-9370
Part Name
166
Remarks
FC4500-50/-60,FC4550-50
FC4500-50/-60,FC4550-50
FC4510-60
FC4500-50/-60,FC4550-50
FC4500-50/-60,FC4550-50
FC4510-60
FC4500-50/-60,FC4550-50
FC4510-60
This part is including in the pen block assy.
FC4500-50/-60,FC4550-50
FC4510-60
FC4510-60
FC4500-50/-60,FC4550-50
FC4500-50/-60,FC4550-50
FC4510-60
FC4510-60
11 PART LIST
