11.3 Main Frame, X Slide Section, and X Drive Section

No. Part No.
1 U792240706 Motor, X Motor
2 U691800530 Flexible Cable, X, A2, FPC06711
U691800520 Flexible Cable, X, A1, FPC06710
3 U054220010 Honeycom board, A2
U022552120 Honeycom board, Panel 3260
4 U771805000 Elect-static Adhesion Panel, 92
U792455701 Writing Panel, PV Panel 4550-50
U792450703 Writing Panel, PV Panel 92x66
U792450704 Writing Panel, PV Panel 4510-60
5 U054112100 X Motor Pulley, 20Z
6 U313068820 Roller B, 688ZZNRAV2S
7 U618122100 X Intermediate Pulley 60
8 U622190131 X Tension Pulley
9 U622190151 Pulley S2M-Z30
10 U370801091 X Drive Belt, 120S2M160V
11 U622190401 X Belt 4250
U622191401 X Belt 4260
12 U035132220 Anti-static Brush
13 U054212140 Wiper
14 U054212201 Roller S
15 U054212212 Roller L
16 U054212221 Roller SC
17 U054212231 Roller LC
18 U308002001 Measure ST13-01BP
19 U772219500 X Sensor Board Assy
20 U621212004 X Rear Slider Base,RK
21 U621212030 Applying Plate
22 U621212020 Block
23 U054212240 Vertical Tension Plate
24 U054212120 Tension Plate
25 U792450701 X Front Slider Assy
26 U792450702 X Rear Slider Assy
FC4500-UM-251-9370
Part Name
162
Remarks
FC4500-50,FC4550-50
FC4500-60, FC4510-60
FC4500-50,FC4550-50
FC45x0-60
FC4500-50
FC4550-50 (U622590050)
FC4500-60 (U022552011)
FC4510-60 (U621210101)
FC4500-50,FC4550-50
FC45x0-60,
This part is including in the slider Assy.
This part is including in the slider Assy.
This part is including in the slider Assy.
This part is including in the slider Assy.
FC4510-60
FC4510-60
FC4510-60
FC4510-60
FC4510-60
11 PART LIST
Q'ty Rank
1 A
1 A
1 A
1 D
1 D
1 B
1 B
1 B
1 B
1 C
5 C
1 C
2 C
2 C
1 A
2 A
2 A
1 C
4 C
4 D
2 D
2 D
1 D
1 B
1 A
1 C
1 C
1 C
1 C
1 C
1 B
1 B
