Chapter 4 SYSTEM MODE
Buttons/Display Fields
MENU
BACK
FORMAT CHANGE
CANCEL
FORMAT
DETAIL
FRONT LABEL
LABEL DETAIL
INITIALIZE
Label Type
Printer
Format No.
Label Print
Label Print Condition
Label Group
4-18
Returns to System Menu 1/2 screen.
Saves data changes and returns to the Label Print Combination Setup
screen.
Displays the printing conditions for each label type.
Press to change the label format number
Change the label format number.
Cancels data changes and returns to the Label Print Combination Setup
screen.
Pressing without numeric entry changes to the format edit screen for the
format number of the selected label type.
Pressing after numeric entry changes to the format edit screen for the
entered number.
Changes to the Print Combination Detail Setup screen.
•
Printer selection
•
Print item addition
•
Format number setting
•
Print condition setting
•
Label print detail information setting
•
Label type addition
Changes to the printer, format number, and cassette number setup screen
for a label to be attached on the tray top.
Change to the label detail setup data (print density, sensor distance, etc.).
The current label format number displayed on the label detail setup screen
becomes the format number at the present cursor position (highlighted
yellow).
Returns the print combination data to the default data.
Moves the cursor up or down.
・ Displays the printer name for each label type.
・ Press the label type field to enable the current label selection.
・ Edit the format number of the selected label type after selection by pressing
the [FORMAT] button.
Select the printer (number) that will be used to print the labels.
Press to display the pop-up screen. Select the printer on the pop-up screen.
Displays the set format number for each label variation.
The default format number is displayed at the initial setting.
Press the display field after entering a format number to set the number.
The format number is automatically set as the default printer format for the
specified format number.
When two or more format numbers are set to one printer, the higher-ranked
format number will be enabled.
Select label printing.
"Yes": Labels will be printed.
"No": Labels will not be printed. In this case, the item will not be
displayed on the Format Setup screen the next time it is displayed.
The selected data will become invalid for total labels.
Set the label print condition.
The priority level when a number of print conditions agree is fixed in the
order that is displayed on the pop-up screen (from top left to bottom right of
the screen).
Press to display the pop-up screen.
Press the desired button to display the label type items of the selected group
and change the color to blue.
Function
