ISHIDA IP-EMZ Service Manual page 146

MAIN BODY UNIT: IP-EMZ
PART CODE:
Refer to DWG No.:
ITEM
1 BRACKET:WEIGH:
2 SPRING:B:2
3 SLIDE:RAIL:LEFT
4 BRACKET:STOPPER
5 BRACKET:HEAD:
6 SHAFT:PRINTER:SLIDE
7 BRACKET AS:PRINT:
8 SLIDE:RAIL:RIGHT
9 BRACKET:SENSOR:
10 BRACKET:MOTOR:
11 PLATE A:SENSOR
12 BLOCK B:SENSOR:
14 FRAME:REAR:
15 SENSOR:RECEIVER:
16 COVER:REAR:
17 BASE:UNDER:
18 FRAME:MIDDLE:
19 FRAME:RIGHT:
20 BRACKET:AS:DISPLAY
22 FRAME AS:UPPER
23 FRAME:LEFT
25 BRAKCET:THERMAL HARNESS:
26 BRACKET:DISPLAY BOARD:
28 L PLATE A:MICHRO SW
29 CRIPPING:PRINT:
30 COVER:HARNESS:THERMAL
31 PLATE A:KEY
32 BASE:KEY:
33 PLATE A:COVER:LOWER
34 COLLAR:
35 BRAKET:STOPPER
36 COVER:PRINTER:CONNECTOR
37 GEAR:FLAT:
38 RAIL:SLIDE:
40 PLATE A:SPRING:SUPPORT
41 STAY:HEAD:THERMAL
42 BUSH:
43 COVER:HEAD:
44 SPRING:COIL:COMPRESSIVE
45 SPRING:COIL:COMPRESSIVE
46 RUBBER PAD:
47 ACCESSORY:BUSH:
48 SPRING:COIL:TENSION
49 ACCESSORY:BUSH:CABLE
50 PWB ACCESSORY:COLLAR BUSH:
51 PWB ACCESSORY:COLLAR BUSH:
ACCESSORY:FASTENER:EDGE
52
54 ACCESSORY:CLAMP:FLAT CABLE
57 CATCH:MAGNET:
58 COVER:SLOT:CF
59 PLATE B:PC:
60 SHEET:HARNESS:UPPER
61 SHEET:HARNESS:LOWER
62 CASE:MAIN BODY:UPPER
63 CASE:MAIN BODY:SIDE
64 CASE:MIAN BODY:FRONT
65 CASE:KEY:
IP-EMZ Service Manual
123-2402-05-0
DESCRIPTION
Chapter 5 MECHANICAL ASSEMBLY
ITEM DESCRIPTION
66 COVER:PRINTER:
67 COVER:CASSETTE:FRONT
68 COLLAR:SPACER
69 COLLAR:SPACER
70 NAME PLATE:EXPLANATION:
71 NAME PLATE:EXPLANATION:
72 MOTOR AS; STEPPING:
73 NAME PLATE:SPECIFICATION:
76 PWB ACCESSORY:CARD SPACER:
79 CAP:
80 SCREW:CROSS TRUSS:
81 SCREW:CROSS TRUSS:
82 SCREW:CROSS TRUSS:
83 TP SCREW:
84 TP TAPPING SCREW:
85 TP SCREW M3X6
87 TP SCREW:
89 SCREW:CROSS TRUSS:
90 SCREW:CROSS FLAT:
91 SCREW:CROSS FLAT:
92 SCREW:CROSS PAN HEAD:
93 SCREW:CROSS PAN HEAD:
94 SCREW:CROSS PAN HEAD:
95 SCREW:CROSS PAN HEAD:BWA S2P2
96 SCREW:CROSS PAN HEAD:
97 SCREW:CROSS PAN HEAD:BWA S2P1
99 CROSS HEAD:HEX BOLT WITH SW/PW
100 PLUS HEX BOLT:
102 SET SCREW:HEX SOCKET:W-POINT
103 E RING:
104 E RING:
105 C RING:FOR SHAFT:
106 TP TAPPING SCREW:T2
108 SCREW:CROSS TRUSS:
109 ACCESSORY:CLAMP:CKN CLAMP
110 ACCESSORY:CLAMP:LWS CLAMP
111 COVER:CARD:
113 TAPE REJECTION
115 ACCESSORY:CLAMP:CKN CLAMP
116 SCREW:CROSS PAN HEAD:
120 L PLATE B:
PWB:P-910:H-2
E1
PWB:P-964:-3
E2
E3 PWB:P-919:B-3
E4 PWB:P-918:A-1
SWITCH AS:SEESAW:
E5
E18 HARNESS:C2:SCALE
E19 SENSOR AS:HEAD:
SENSOR AS:LABEL:RECEIVER
E21
E24 KEY BOARD AS:
E25 POWER SUPPLY:SWITCHING:
PHOTO INTERRUPTOR:TRANS:
E26
E27 PHOTO INTERRUPTOR:TRANS:RECEIV
E34 PWB:P-967:-1 Ethernet Junction Board
E39 Noise Filter
5-5
