ISHIDA IP-EMZ Service Manual page 84

Buttons/Display Fields
MENU
PAGE
TCP/IP Setup
System Data
Auto Program
Label Combination
Format Setup
Print Items
File Check
File I/O
Free Master
Link Master Error
Display Error Log
SRAM Data I/O
File Transfer
Meat Cut Setup
EU Specifications
Traceability Setup
Special Time
CF File I/O
Machine No.
Exchange Rate
Scanner Setup
IP-EMZ Service Manual
Changes to the System Menu 1/2 screen.
Press to turn over the screen.
Changes to the TCP/IP Setup screen.
Various data can be set according to consultation of your SE when this
machine is connected to a computer.
Changes to the System Data Setup screen.
Processing can be selected when the production order is completed.
Select master file change (each PLU/unit price).
Changes to the Auto Program Setting screen.
Select whether or not to update data and reflect it to the PLU master file
automatically for each item.
Changes to the Label Print Combination Set screen.
Set the label type, format, and details.
Changing to the label details setting and the format edit screen is also
possible as an extended screen.
This is not displayed when no printer is connected.
Changes to the Format Setup screen.
Create, edit, and delete the label formats.
Changes to the Print Item Setting screen.
Set the label print items and print position.
Changes to the File Check screen.
Initialize all internal master files.
Changes to the File I/O screen.
Perform master file I/O processing with the IF-21FD.
Changes to the Free Message Name Registration screen.
Set the free master names 1-5.
Changes to the Link Master Error Setup screen.
Set the error processing when the character string master file linked with a
PLU is not registered.
Changes to the Display Error Log screen.
Check past error history (500 or less).
Changes to the SRAM Data Input/Output screen.
Set IF-21FD and the SRAM data I/O.
Changes to the File Transfer Menu screen.
Perform CF card and SRAM data input and output.
USA specification
It relates to the yield of a cut.
Setting for Traceability.
The row of time data can be rearranged arbitrarily.
Perform master file I/O processing with the CF card.
Can only use "Edit" to modify machine number.
Push the [EDIT] button and edit the machine number.
It can be composed of numbers, Letters and symbols.
The length of machine number is limited to 20.
Input the exchange rate for local currency.
Select the currency of Setting to barcode.
Input barcode system of scanner
Chapter 4 SYSTEM MODE
Function
4-5
