3.12 OPTION CHECK

Press the [Option Check] button on the Test Menu screen. Then, the Option Check screen appears.
This procedure is used to perform scanner and card slot checks.
Buttons/Display Fields
MENU
Scanned Data
Slot 1 Check
Slot 2 Check
Display Status
IP-EMZ Service Manual
Option Check Screen
Returns to the Test Menu 1/2 screen.
Displays the OCR data when a barcode is read with the scanner.
Insert the formatted CF card (8M, 16M) and press the [EXECUTE] button to
execute an operation check.
Insert the formatted CF card (8M, 16M) and press the [EXECUTE] button to
execute an operation check.
"Operating" is displayed during execution.
"Normal" is displayed when the execution has ended normally.
"Abnormal" is displayed when execution has ended abnormally.
Chapter 3 TEST MODE
Function
3-27
