ISHIDA IPC-WP Operation Manual

(WP)
North America
OPERATION MANUAL
• Do not carry out installation, operation, service or
maintenance without thoroughly understanding of the
contents of this manual.
• Keep this manual available at all times during installation,
operation, service, and maintenance.
ISHIDA CO., LTD.
You can help improve this manual by calling attention to errors
and by recommending improvements.
Please convey your comments to the nearest Ishida Company
regional representative.
Copyright  2002 by Ishida Co., Ltd. All Rights Reserved.
No part of this manual may be reproduced in any form, by
mimeograph or any other means, without written permission of
the publisher.
2007 Jan.
1. Cautions for Handling
To ensure the safe operation of this machine, the general safety considerations
below must be followed:
- Always operate the scale on a level surface.
- Do not disassemble the scale.
- Do not allow any liquids to come into contact with the scale.
- Do not drop or apply a strong shock to the scale.
- When cleaning the scale, only use a soft dry cloth wetted with a neutral
cleanser. Never use thinner or other volatile liquids.
- Do not use your scale in abnormal conditions.
If smoke, disgusting smell, or any other abnormality is detected from
the scale, immediately disconnect the power supply cable plug from
the outlet and contact the nearest ISHIDA regional representative for
repair. Continued use of scale under such abnormal conditions may
cause a fire or electric shock. For your personal safety, never repair the
scale by yourself.
2. Name and Function of Each Component
2-1 External View of the Scale
2-2 Function of Each Key
!
Thank you
Used to turn ON/OFF power of the scale.
Used for zero adjustment.
When the Stable
mark stops flashing,
Used to set tare weight. the weight is stable.
Used for auto-power function.
Also used to switch between "lb" and "kg".
- Do not insert/remove the plug in/from the outlet with wet fingers.
- Do not remake the electrical plug or power cable.
- Do not pull strongly, break, or remake the power cable.
- Do not leave any items on the weighing platter. This can damage the
measuring equipment.
- Do not peel off the seal affixed to the scale body.
Always operate the scale with the same rated AC power supply shown on
the specification plate.
- Avoid Locating the Scale in the Following places:
- A place of low temperature, high temperature or high humidity
- A place frequently exposed to vibration
On an unstable floor or table
Displays are provided on both sides of scale.
(One-side-display model is also available.)
When the Zero mark When the NET
is displayed, the mark is displayed,
actual weight is "0". the tare weight is
deducted.
Battery check mark
When this mark is
displayed, battery is
nearly depleted.
Replace the
batteries.
0204A
