Chapter 4 SYSTEM MODE
4.9

FILE CHECK

This screen is used to confirm master files such as PLU master, Store master, Extra message master
files, etc. registered in this machine
Buttons/Display Fields
MENU
Master Name
Number
Memory Information
PLU Master
Memory Remaining
Display Bar
SELECT
4-26
File Check Screen
Returns to the System Menu 1/2 screen.
Displays master names (only master files that can be processed by the
IF-21FD and master files with the number "0").
Press the desired field to make a selection and change the color to light blue.
Displays the number of data registered in the machine (only master files that
can be processed by the IF-21FD and master files with the number "0").
Press the desired field to make a selection and reverse the color to light blue.
Displays remaining SRAM memory in bytes.
(Zero suppression, Max.8 digits)
Calculates the number of items that can be registered based on the amount
of remaining memory.
Number of Items = Remaining amount ÷ (Fixed PLU master parts + PLU
name character string 128 bytes + One unit price master)
Displays the amount of memory remaining in black.
Press to move the master information list display page up/down.
Press to move the cursor position in the master information list display
up/down (cursor is yellow).
Select master files for initialization.
Press the desired field where the cursor is positioned to select a master file.
This will select an unselected field or unselect a selected field.
Selecting a field will change the field where the cursor is positioned light blue.
Placing the cursor on a selected item will change the color of the field to
green.
Function
