Chapter 3 TEST MODE
Buttons/Display Fields
Head Resistance
Head Error Check
Memory Initialization
Head Type
Usage Distance
Cassette Status
Head Up Sensor
Label Sensor Level
Peel Sensor Level
3-16
Displays thermal head resistance (Ω, zero suppression).
Touch the [SET] button after numeric entry to set new head resistance.
Data range is 0-999.
The buzzer will sound if data is set beyond the specified range.
Touch the [SET] button without numeric entry to automatically set head
resistance.
"Auto Setting" is displayed during the execution of automatic settings.
Execute thermal head error check.
"Processing" is displayed during processing.
"Normal" is displayed when processing has ended normally.
"Abnormal" is displayed when processing has ended abnormally.
Initialize printer memory.
"Processing" is displayed during processing.
"Normal" is displayed when processing has ended normally.
"Abnormal" is displayed when processing has ended abnormally.
Execute sensor levels, back feed calibration, initialization of the protection
setting value against head temperature rise, and acquisition of the head
resistance, and initialization of label and cassette master data for the selected
printer.
Be sure to execute this procedure when the P-910 has been replaced.
Displays thermal head type name.
One of the following three types can be set:
Press the [SET] button after numeric entry to set the desired head type.
Default data: "0" LH4114 (8 dots/mm standard).
1: LH4116 (8 dots/mm history control). Printing is not possible with the
LH4116 head (8 dots/mm history control) installed. Printing can be
normally performed when "1" is set and the LH4114 installed.
2: BHP4312 Set the BHP4312 (8 dots/mm 2 colors) when using two color
specifications. Set the DIP switch on the thermal board and "Thermal
paper type" in "Print Adjustment 2/2" screen to "2: 2 color label".
Thermal head movement distance ("km", zero suppression) is displayed.
Touch the [SET] button to clear head movement distance.
Refer only when adjusting the cassette applicable printer.
: No cassettes are inserted.
: Cassette 1 is inserted.
The same sensor as [Head Up Sensor] is used.
Displays head status.
"ON" is illuminated when the head is set normally.
"OFF" is illuminated when the head is up.
Displays label sensor level.
Touch this button to finely adjust the label sensor level (display field will
change to green) and press the (
again to change the display to white and set adjustment data. The level range
is 0-255.
Displays peel sensor level.
Touch this button to finely adjust the peel sensor level (display field will
change to green) and press the (
again to change the display to white and set adjustment data. The level range
is 0-255.
Function
) adjustment buttons. Touch this button
) adjustment buttons. Touch this button
