Chapter 3 TEST MODE
3.3

KEY CHECK MENU

Press the [Key Check] button on the Test Menu screen. Then, the Key Check Menu screen appears.
Buttons/Display Fields
MENU
Numeric Key Check
Touch Panel Adjustment
3-4
Key Check Menu Screen
Returns to the Test Menu 1/2 screen.
Changes to the Numeric Key Check screen.
Press the stroke keys on the keypad, then the corresponding button will
change its color black on the screen.
Changes to the Touch Panel Adjustment screen.
Adjust touch panel press position by pressing the center marks (+) on the
two buttons located at the top left and the bottom right of the screen using
a pointed object, and finally pressing the center mark (+) on the
acknowledge button.
Function
