Chapter 6 ELECTRIC ASSEMBLY
6.6

LAN PC BOARD (P-967-1)

6.6.1

BOARD LOCATION

This board connects a computer, etc. using TCP-IP.
It is located in the main body.
6.6.2

I/O SIGNALS

XJ1
No.
1
2
3
6
4.5.7.8
XJ2
No.
1
2
3
6
4.5.7.8
6-14
Signal name
LAN TD+
LAN TD-
LAN RD+
LAN RD-
GND
Signal name
LAN TX+
LAN TX-
LAN RX+
LAN RX-
GND
Direction Other end
←
←
P-910
→
(XJ18)
→
-
Direction Other end
→
→
←
LAN
←
-
