Chapter 3 TEST MODE
Buttons/Display Fields
Test Print
(Back Feed Control)
Paper Type
Back Feed Length
Heat Protection
3-24
Select the back feed function when test printing is performed.
Press either "YES" or "NO" to select the desired function and change the
button color to blue.
Note: This setting is applied only to the test print. Back feed settings for
normal printing can be performed in the Label Detail Settings in the
System Menu.
Displays the type of thermal paper selected. Press the [SET] button after a
numeric entry to set the type of thermal paper to be used in the printer. The
data range is 0-9 with the following parameters:
1: Standard label
2: Two color label
3-9: Not registered
The default value is "1".
A loss is caused in the feeding length for each roller due to the reverse
rotation of the motor, gears, and print roller during back feed operation. This
function is used to make up that loss.
It does not influence the store name, address, and ruled lines for each
existing format. However, it is used in the case of a format without sufficient
space.
The top and bottom dimensions (approximation) of the set label and the back
feed correction length (mm). Press the top/bottom select button to determine
the label top/bottom type for correction length.
Select one of three types: 45mm, 60mm, or 80mm. The selected size field
changes to blue. Press the correction length display field after a numeric
entry to set the correction length for the selected top and bottom dimensions.
The data range is 0.0-9.9mm.
Displays the heat protection selection for the set head. Press the [SELECT]
button to select head temperature increase protection. The button color will
change to blue.
No: Print even if the head temperature increases. (Default)
Yes: Stop printing for about 0.5 seconds if the head temperature increases.
The print density is high, and it is a level where the temperature over rises by
1000 piece continuous printing. The print density is high and the head will
overheat after continuously printing 1000 labels.
Usually set to "No".
Function
