Chapter 4 SYSTEM MODE
Buttons/Display Fields
MENU
Operation Select
Index Name Setting /
Select
File Name Select
(SELECT/
ALL SELECT)
EXECUTE
4-42
Returns to the System Menu 1/2 screen.
MAIN→
Select to output main body master data to the IF-21FD FD and SRAM main
body data (set system data for each machine) to the CF-1 (main program
CF).
(File name: sram.dat)
→ MAIN
Select when replacing the main board or copying all data to another machine.
Backup master data and permanent storage field data (system data for each
machine) can be input to SRAM.
(File name: sram.dat.)
SAVE DATA
Select to save the set the machine unique data in the CF-1.
(File name: sram.dat.)
RESTORE DATA
Select to restore machine unique data (file name: sram.dat.) stored in the
CF-1.
Press the corresponding button to set (edit) or select the desired index
name(s).
The output master data selection screen is displayed when the index name is
fixed.
Press one of these buttons to select the desired output file.
Press to move the list index information display page up/down.
Press to move the cursor position in the index information list display
(highlighted yellow) up/down.
Output the selected file. The confirmation screen is displayed. Press
[EXECUTE] to initiate processing.
Press [CANCEL] to cancel processing and return to the previous screen.
The permanent storage data backup confirmation screen is displayed when
file output ends normally.
Press [EXECUTE] to copy SRAM permanent storage data to the main
program CF. (File name: sram.dat)
Function
