4.11 FREE MESSAGE NAME REGISTRATION
With this machine, master files are prepared at the factory.
On this screen, there are five areas named Free 1 through Free 5 you can freely use. You can change
these master name as you like.
Note: When a free master name is changed the updated master name is displayed thereafter.
Buttons/Display Fields
MENU
EDIT
IP-EMZ Service Manual
Free Message Name Registration Screen
Returns to the System Menu 1/2 screen.
Press to move the cursor position (highlighted yellow) up/down.
Press to move the cursor position to either Free 1 or Free 5.
Press change to the free master name edit screen at the present cursor
position.
Chapter 4 SYSTEM MODE
Function
4-31
