ISHIDA IP-EMZ Service Manual page 155

Chapter 6 ELECTRIC ASSEMBLY
XJ10
No.
1,3,4,6,
8-15
2
5, 7
XJ11
No.
1
2
3
4-5
XJ18
No.
1
2
3
4-5
6-6
Signal name
LCD control signal
Not used
GND
Signal name
DC+12V
GND
Buzzer ON/OFF
Not used
Signal name
LAN TD+
LAN TD-
LAN TD+
LAN TD-
Direction Other end
←→
P-919 (XJ1)
To P-917 via the
-
above-mentioned PC board.
-
Direction Other end
→
P-919 (XJ6)
-
To P-917 via the
→
above-mentioned PC board.
-
Direction Other end
→
→
P-967-1 (XJ1)
←
←
