ISHIDA IP-EMZ Service Manual page 162

XJ11
No.
1
2
3
4
5
6
XJ12
No.
1
2
3
4
5
6
XJ13
No.
1
2
3
4
5
6
7
8
9
XJ14
No.
1
2
3
4
5
6
7
8
9
XJ15
No.
1
2
3
4
5
6
7
8
9
IP-EMZ Service Manual
Signal name
I2NET D
I2NET D
I2NET EN
I2NET EN
GND
FG
Signal name
I2NET D
I2NET D
I2NET EN
I2NET EN
GND
FG
Signal name
Not used
Not used
GND
I2NET EN
I2NET D
Not used
FG
I2NET EN
I2NET D
Signal name
Not used
Not used
GND
I2NET EN
I2NET D
Not used
FG
I2NET EN
I2NET D
Signal name
RS232C CD
RS232C RxD
RS232C TxD
RS232C DTR
RS232C SG
RS232C DSR
RS232C RTS
RS232C CTS
RS232C RI
Chapter 6 ELECTRIC ASSEMBLY
Direction
←→
←→
←→
ILAN
←→
(Option 1)
-
-
Direction
←→
←→
←→
ILAN
←→
(Option 1)
-
-
Direction
-
-
-
←→
ELAN
←→
(INLINE)
-
-
←→
←→
Direction
-
-
-
←→
ELAN
←→
(INLINE)
-
-
←→
←→
Direction
←→
←→
←→
←→
ELAN
-
(INLINE)
←→
←→
←→
←→
Other end
Other end
Other end
Other end
Other end
6-13
