Display Modes

Base Display
Alarm Display

Graphic Display Menus

Top Menu
32
The Acme Packet 4600 graphic display defaults to one of two display modes:
•
Base display is the default and indicates a properly-functioning Acme Packet
4600.
•
Alarm mode becomes the default display mode when any alarms are active on
the Acme Packet 4600. Active fault information is continuously displayed on the
graphic display.
The base display shows the type of Acme Packet 4600 running. This information
appears when the system first starts up and when the graphic display times out at
any menu level.
ORACLE
AP4600
The base display of a Acme Packet 4600 in an HA node includes additional
information applicable to its HA state.
The alarm display replaces the base display during an alarm condition. The alarm
display informs you of what symptoms are currently causing alarms. The number
and type of alarms appear on the Acme Packet 4600 graphic display, which indicates
either a link alarm or a hardware alarm. For example, if there are two link alarms
present on the Acme Packet 4600, the display appears like this:
2 LINK ALARMS
If the graphic display indicates an alarm condition, you can use the ACLI display-
alarms command to display the details of the alarm. When an alarm condition is
cleared, the base display replaces the alarm display. To clear an alarm, you must
execute the ACLI clear-alarm command or resolve the cause of the alarm.
The Acme Packet 4600 System graphic display lets you access the five display menus
for quick access to the system's current status.
The top menu provides top-level access to information in distinct categories of
system functionality.
To access the top menu from the base display or alarm display:
1. Press the Enter button. The first entry in the top menu appears.
2. Press the Up and Down buttons to scroll through the top menu categories. The
top menu rolls over when you reach the top or bottom of the menu.
The top menu displays only one category at a time. Press the Enter button to
select a displayed category and show its submenu information.
