Result from Pressing Up/Down Buttons
Result from Pressing Enter Button
INTERFACE Menu
Acme Packet 4600 Hardware Installation and Maintenance Guide
Figure 3 - 38. Scrolling Through Menu Categories on the Graphic Display
After 30 seconds of displaying a menu option or submenu information without any
user input, the system automatically returns to the base display during normal
operating conditions or to the alarm display during an alarm condition.
Figure 3 - 39. Acme Packet 4600 Menu Options (Exploded View)
The INTERFACE menu allows you to scroll through a list of all configured physical
interfaces, including the management and media physical interfaces and the
loopback interface.
