DC Power Supply
Physical
Dimensions
Fan Module
Specifications

Electrical Specifications

Power Supply
Input Circuit Fuse
Requirements
Alarm Port Dry
Contact Current
Limits
120
This table lists the physical dimensions and weight of the Acme Packet 4600
DC power supply.
Table 7 - 20. Acme Packet 4600 DC Power Supply Physical Dimensions
Specification
Height 1.575" (4.00 cm)
Width 2.146" (5.45 cm)
Depth 13.26" (33.68 cm)
Weight 2lbs., 5 oz. (1.05 kg)
Important: This equipment is intended for installation in Network
Telecommunication Facilities.
This table lists the fan module specifications for the Acme Packet 4600.
Table 7 - 21. Acme Packet 4600 Fan Module Specifications
Specification
Number of Fans
Total Maximum Airflow
Refer to the following tables for information regarding the electrical
specifications of the Acme Packet 4600 System.
This table lists the input circuit fuse and cable size requirements for the Acme
Packet 4600.
Table 7 - 22. Acme Packet 4600 Power Supply Input Circuit Fuse Requirements
Power Circuit Fuse Rating
120 VAC 15 AMP
240 VAC 7.5 AMP
-48 VDC 30 AMP
This table lists the electrical characteristics of the Acme Packet 4600 alarm port.
Table 7 - 23. Acme Packet 4600 Alarm Port Dry Contact Current Limits
Specification
Max AC switching current
Max DC switching current
Description
Description
5
100 CFM
Power Cable Size
18 AWG
18 AWG
10 AWG
Value
0.3 A @ 125 VAC
1 A @ 30 VDC
