Electromagnetic Immunity, Curve System

IEC 60601-1-2
Curve is intended for use in professional healthcare facilities only. The following lists all applicable
immunity tests and standards, as well as the used compliance levels:
Immunity Test
Electrostatic Discharge -
Contact
Electrostatic Discharge -
Air
Radiated RF EM Fields
Electrical Fast Transient/
Burst - Input AC Power
Port
Electrical Fast Transient/
Burst - Signal Input/Output
Ports
Surge - Input AC Power
Port Line-to-Line
Surge - Input AC Power
Port Line-to-Ground
Conducted Disturbances
Induced by RF
Power Frequency Magnet-
ic Field
a
Only tested at ISM frequencies.
Test fre-
quency
(MHz)
385
450
710
745
780
System and Technical User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
Standard
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
Band Service
(MHz)
380 - 390 TETRA 400
GMRS 460,
430 - 470
FRS 460
LTE Band 13,
704 - 787
17
IEC 60601-1-2 Test
Level
±8 kV
±2 kV, ±4 kV, ±8 kV,
±15 kV
3 V/m
80 MHz to 2.7 GHz
80% AM at 1 kHz
±2 kV
100 kHz repetition
frequency
±1 kV
100 kHz repetition
frequency
±0.5 kV, ±1 kV
±0.5 kV, ±1 kV, ± 2
kV
3 V
0.15 MHz to 80 MHz
a
6 V
80% AM at 1 kHz
30 A/m
50 Hz or 60 Hz
Modulation Maxi-
mum
(W)
Pulse modula-
tion
1.8
18 Hz
FM
± 5 deviation 2
1 kHz sine
Pulse modula-
tion
0.2
217 Hz
Compliance Level
±8 kV
±2 kV, ±4 kV, ±8 kV,
±15 kV
3 V/m
80 MHz to 2.7 GHz
80% AM at 1 kHz
±2 kV
100 kHz repetition fre-
quency
±1 kV
100 kHz repetition fre-
quency
±0.5 kV, ±1 kV
±0.5 kV, ±1 kV, ± 2 kV
3 V
0.15 MHz to 80 MHz
a
6 V
80% AM at 1 kHz
30 A/m
50 Hz or 60 Hz
Distance Immunity
Compli-
(m)
ance Level
(V/m)
0.3 27
0.3 28
0.3 9
173
