Applied Part Leakage Current (Type BF) (for Optional EM Tracking Unit)

10.3.3 Applied Part Leakage Current (Type BF) (for Optional EM Tracking Unit)
General Information
The following points are defined for the EM Tracking Unit.
An adapter is necessary for the EM connecting unit. This adapter must have all connectors short
circuit on the plug.
Use the IEC 62353:2014 Chapter 5.3.4.3.2 alternative measurement and connect the applied part
to the input socket in your measurement device.
For example:
Measurement Point
Point Tested
Adapter plug on EM con-
necting unit (measure all
four sockets)
154
Figure 66
System and Technical User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
Measured Value Test
Passed?
