Cart Arms and Monitors
Clean the touchscreens before use.
Protecting Touchscreen Surface
Warning
Do not use damaged touchscreens. Always check touchscreen condition before beginning
a procedure.
Do not use sharp tools on the touchscreen.
Monitor Cart Arm Components
No.
①
②
③
④
Do not attach or hang anything on the Monitor Cart arms. This may cause the cart to tip
over.
Do not lean on the Monitor Cart arms.
Related Links
2.3 Proper System Handling on page 25
32
①
Component
Upper arm
Monitor joint
Articulated arm
Lower arm
System and Technical User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
② ③
Figure 8
④
