COMPLIANCES AND SPECIFICATIONS
5.4.3

Electromagnetic Immunity, Curve System

IEC 61000-4-2,IEC 61000-4-4,IEC 61000-4-5, IEC 61000-4-8,IEC 61000-4-11
Immunity Test
Electrostatic dis-
charge (ESD) IEC
61000-4-2
Electrical fast tran-
sient/burst IEC
61000-4-4
Surge IEC
61000-4-5
Power frequency
(50/60 Hz) magnet-
ic field IEC
61000-4-8
Voltage dips, short
interruptions and
voltage variations
on power supply in-
put lines IEC
61000-4-11
NOTE: U
IEC 61000-4-6,IEC 61000-4-3
Immunity
Test
Conducted
RF IEC
61000-4-6-
Technical User Guide Rev. 1.2 Curve Dual Display, Curve Single Display Ver. 1.0
IEC 60601 Test Level and
Compliance Level
± 6 kV contact
± 8 kV air
± 2 kV for power supply
lines
± 1 kV for input/output lines
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
3 A/m
<5% U (>95% dip in U
T
for 0.5 cycle
40% U (60% dip in U
T
5 cycles
70% U (30% dip in U
T
25 cycles
<5% U (>95% dip in U
T
for 5 s
is the AC mains voltage prior to application of the test level.
T
IEC 60601 Compliance
Test Level Level
3 Vrms 150
kHz to 80 3 V
MHz
Electromagnetic Environment - Guidance
Floors should be wood, concrete or ceramic
tile. If floors are covered with synthetic mate-
rial, the relative humidity should be at least
30%.
Mains power quality should be that of a typi-
cal commercial or hospital environment.
Mains power quality should be that of a typi-
cal commercial or hospital environment.
Power frequency magnetic fields should be
at levels characteristic of a typical location in
a typical commercial or hospital environment.
)
T
Mains power quality should be that of a typi-
cal commercial or hospital environment. If the
) for
T
Curve system user requires continued opera-
tion during power mains interruptions, it is
) for
T
recommended that the Curve system be
powered from an uninterruptible power sup-
)
ply or a battery.
T
Electromagnetic Environment - Guidance
Portable and mobile RF communications equip-
ment should be used no closer to any part of the
Curve system, including cables, than the rec-
ommended separation distance calculated from
the equation applicable to the frequency of the
transmitter.
Recommended separation distance:
,
d = 1 2 P
,
80 MHz to 800 MHz
d = 1 2 P
,
d = 2 3 P 800 MHz to 2.5 GHz
