Panels and System Ventilation
• Double Layer±R
• CD-R
• CD-RW
Only insert standard CD/DVDs of 120 mm diameter. Do not insert irregularly shaped CD/
DVDs.
Connection Panel
③
②
①
No.
①
②
③
④
⑤
⑥
40
Component
Imaging Input 2:
• DVI In
• SDI In 2
Imaging Input 2:
• S-Video In
• Composite In 1
• SDI In 1
Display Port
USB
Data:
• Hospital Network
• Intraoperative Data
• Tracking
Microscope:
• HUD
• Communication
System and Technical User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
Figure 14
④
⑤
⑥
