ELECTRICAL SAFETY
10.2.2

Test Steps

Test Prerequisites
When performing recurrent tests:
• Perform required test steps in the order defined.
• Measure all areas of the system indicated in the following chapters.
• All tests must be passed before the device can be considered safe.
• The calibration of the measuring device must be valid at the time of measurement.
NOTE: The measurement outlet connection of the measuring device must remain established
during the entire measurement cycle. If you unplug the measurement outlet during measurement,
the measuring device recognizes that the connection is no longer established and you will need to
repeat the entire test.
If the device does not pass a test, it must be repaired by Brainlab support. After repair, repeat the
entire electrical safety test from the beginning.
Safety Inspection Form
• Print out or make a copy of the safety inspection form.
• Enter the inspection results.
• Compare measured values with the critical values from the the safety inspection form to
determine if the test has been passed.
• Keep form as a record of the inspection.
Related Links
10.2.3 Safety Inspection Form - Recurrent Tests on page 148
Required Test Steps
Step
1.
2.
3.
4.
5.
6.
7.
System and Technical User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
Perform visual inspection.
Check protective earth resistance.
Check equipment leakage current.
Check the applied part leakage current (type BF) (for optional EM Tracking Unit).
Perform functional test.
Report and evaluate results.
Check and prepare system for normal use.
147
