No.
7
8
11.3 Indicator
The interface expansion module supports real-time IO monitoring, and provides a sufficient
number of indicators, as shown below.
No.
1
2
3
4
5
X86 Open Platform
Interface Name
RS485 serial port
RS232 serial port
Figure 11-4 Indicator
Table 11-3 Indicator Description
Indicator Name
POWER
IN 1
IN 2
IN 3
IN 4
User Manual
·
Description
It is the RS485 serial port.
It is the RS232 serial port.
Description
Power indicator
Input signal 1 indicator
Input signal 2 indicator
Input signal 3 indicator
Input signal 4 indicator
60
