For specific Line Out Activation Event, please refer to following table for details.
No. Name
1 Off
AcqusitionStartActive
2
AcqusitionStopActive
3
FrameBurstStartActive
4
FrameBurstEndActive
5
ExposureStartActive
6
CountActive
7
TimerActive
8
HardTriggerActive
9
SoftTriggerOut
10
SoftTriggerLevelOut
11
3. Set Line Out Delay Time(μs), Line Out Duration Time(μs), or LineOut Ahead Time(μs) for
different output events according to actual demands, as shown below.
X86 Open Platform
·
Table 6-1 Output Event
Description
It refers to disable Line Out Activation Event.
It refers to output one I/O edge signal when starting
acquisition.
It refers to output one I/O edge signal when stopping
acquisition.
It refers to output one I/O edge signal when starting
triggering and acquiring images under Burst mode.
It refers to output one I/O edge signal when stopping
triggering and acquiring images under Burst mode.
It refers to output one I/O edge signal when starting
exposure.
It refers to output one I/O edge signal when counter
output is enabled.
It refers to output one I/O edge signal when timer output
is enabled.
It refers to output one I/O edge signal when hardware
trigger acquisition.
It refers to output one I/O edge signal when software
trigger acquisition.
It refers to output one I/O level signal when software
trigger acquisition.
