Chapter 3 I/O Interface and Indicator

3.1 I/O Interface

The USB3.0 board level camera has 2 kinds of I/O interface, including 6-pin and 4-pin.

3.1.1 6-Pin I/O Interface

Refer to the figure and table below for the pin definition of the 6-pin I/O interface.
Pin
Signal
1
GPIO2
2
Reserved
3
GPIO1
4
GND
5
Reserved
6
Reserved
Refer to the pin definition and labels attached to the I/O cable to wire the camera.
3.1.2 4-Pin I/O Interface
Refer to the figure and table below for the pin definition of the 4-pin I/O interface.
USB3.0 Board Level Camera
Figure 3-1 6-Pin I/O Interface
Table 3-1 Pin Definition of 6-pin I/O Interface
I/O Signal Source
Line 2 signal line
--
Line 1 signal line
Line 1/Line 2 signal ground
--
--
User Manual
·
Description
Can be configured to input or output
--
Can be configured to input or output
Signal ground
--
--
4
