X86 Open Platform User Manual
·

9.2 Set Light Source

For some models of X86 open platform that have light source and lens cover, you can set light
source via MVS client.
Steps:
1. Click Light Source Control > Enable Light.
2. Enable Enable Light.
Figure 9-3 Enable Light
3. (Optional) Enter proper value in Lighting Duration(µs) and Lighting Ahead Time(µs) to set
light source flashing time, and ahead time before exposure respectively.
For models of X86 open platform that do not have light source and lens cover do not support this
function.

9.3 Save and Load User Set

The device supports 4 sets of parameters, including 1 default set and 3 custom sets. The relation
among 4 sets of parameters is shown below.
User
Parameter 1
Device
load
Current save User
Default
Parameter
Parameter 2
Parameter
load
User
Parameter 3
Figure 9-4 Parameter Relation
You can save parameters, load parameters and set user default as shown below.
44
