4.1 Main Window

After connecting to the device, the MVS client can read the device attributes and display them in
tree format. The main window and its description are shown in Figure 4-1 and Table 4-1
respectively.
For specific main window of the MVS client, please refer to the actual one you got.
No. Area Name
1 Menu Bar
2 Control Toolbar
3 Device List Panel
X86 Open Platform

Chapter 4 Device Setting

Figure 4-1 Main Window
Table 4-1 Description of the Main Window
Description
Function modules including File, View, Settings, Tool,
and Help.
The control toolbar provides quick operations for
images.
Display current device list, and provide icons for
connecting/disconnecting device, start/stop acquisition,
and refreshing device list.
