X86 Open Platform User Manual
·
Figure 8-9 Set Gamma Correction

8.7 Set Brightness

The X86 open platform supports brightness function. After setting brightness, the device will
automatically adjust exposure or gain to let the image brightness reach target value.
You should enable Once or Continuous exposure mode, or Once or Continuous gain mode first
before setting brightness.
Steps:
1. Click Image Setting > Brightness.
2. Enter proper value in Brightness according to actual demand.
Figure 8-10 Set Brightness
Under Once or Continuous exposure mode, or Once or Continuous gain, the higher the brightness
value, the brighter the image will be.

8.8 Set Image Reverse

The X86 open platform supports horizontal reverse image output. Horizontal reverse refers to the
image reverses in a horizontal way. You can set image reverse as shown below.
Steps:
1. Click Image Setting > Mirror X.
2. Enable Mirror X according to actual demands.
Figure 8-11 Enable Mirror X
37
