HikRobot X86 User Manual page 69

No. Interface Name
2 Output interface
3 Input interface
4 Light source control interface
5 VGA expansion interface
6 Power interface
7 Device interface
Figure 11-3 Back Side of the Interface Expansion Module
Table 11-2 Interfaces on the Back Side of the Module
No. Interface Name
1 Input interface
2 Output interface
3 Input/output interface
4 USB expansion interface
5 USB expansion interface
6 USB expansion interface
X86 Open Platform
·
Description
It outputs I/O signal.
It inputs I/O signal.
It controls light source.
It refers to VGA display.
It provides power supply.
It connects X86 open platform.
Description
It inputs I/O signal.
It outputs I/O signal.
It inputs/outputs I/O signal.
It is the USB expansion interface.
It is the USB expansion interface.
It is the USB expansion interface.
59
User Manual
