No.
6
7
8
9
10
11
12
13
14
15

11.4 I/O Wiring

The interface expansion module currently only supports 7 in/7 out IO. Please refer to the
instruction below when wiring.
 I/O interface input wiring method is shown below. Input voltage ranges from 5 VDC to
30 VDC.
Expansion Interface
Board
X86 Open Platform
Indicator Name
Description
IN 5
Input signal 5 indicator
IN 6
Input signal 6 indicator
IN 7
Input signal 7 indicator
OUT 1
Output signal 1 indicator
OUT 2
Output signal 2 indicator
OUT 3
Output signal 3 indicator
OUT 4
Output signal 4 indicator
OUT 5
Output signal 5 indicator
OUT 6
Output signal 6 indicator
OUT 7
Output signal 7 indicator
12-pin Power Cable
IN_COM
IN0/1/2
Figure 11-5 I/O Input Wiring
User Manual
·
61
