11.1 Overview

The X86 open platform is compatible with interface expansion module that is compact, easy to
install. The module has 1 VGA interface, 3 USB 2.0 interfaces, 1 RS232 serial port, and 1 RS485
serial port, 1 light source controlling port, and a 7 in/7 out IO port.

11.2 Interface

The interfaces of interface expansion module are shown below.
No.
1
X86 Open Platform

Chapter 11 Interface Expansion Module

Figure 11-1 Interface Expansion Module
Figure 11-2 Front Side of the Interface Expansion Module
Table 11-1 Interfaces on the Front Side of the Module
Interface Name
Power Switch
User Manual
·
Description
It switches on or off power.
