PLANET ECLIPSE EGO TEN Operator's Manual page 77

o-rinG location
inline regulator Swivel
barrel back
lPr body*
016
inline regulator Piston
inline regulator Top (Nbr 90)
barrel Front
bolt
015
lPr body*
14 2
X
valve guide
lPr Piston
013
* = eitHer 016 or 14
all o-rinGs are nbr 70 durometer unless otHerWise stated.
o-rinG
012
011
010
009
008
007
006
2 o-rinGs can be used on tHe lPr bodY due to tHe fact tHat it
x
Has tWo sealinG o-rinGs.
location
bolt insert
back of the rammer
rammer Cap
inline regulator bottom
inside lPr body
inside rammer Cap
rammer Front bumper
rammer Shaft
OOPS insert External
inline regulator Adjuster Screw
Torpedo
lPr Adjuster Screw
OOPS insert internal (Nbr 90)
