PLANET ECLIPSE EGO TEN Operator's Manual page 22

settinG tHe triGGer
The Ego10 provides the user with the option to use
either a micro-switch or an Opto sensor as the means for
detecting trigger pulls. before you begin to adjust and set
your trigger, you must first select the method of trigger
detection that you wish to use by entering the Main menu
and making your selection from the
page 42).
There are five adjustment points on the trigger – the
stop trigger screw
return strength screw,
and the
As standard each Ego10 comes with a factory set trigger
travel of approximately 2mm in total length; one millimeter
of travel before the firing point and one millimeter of travel
after the firing point, and the trigger detection method set
to Opto.
The front stop trigger screw
trigger travel prior to the marker firing. Turn this screw
clockwise to reduce the amount of travel. Do not turn the
screw too far or the trigger will be pushed past the firing
point and the marker will not work. Turn this screw counter
clockwise to increase the amount of trigger travel
fiGure 6.1)
The rear stop trigger screw
travel after the marker has fired. Turn this screw clockwise
to reduce the amount of travel. Do not turn the screw too
far or the trigger will be prevented from reaching its firing
point and the marker will not work. Turn this screw counter
clockwise to increase the amount of travel
6.2) .
The magnet return strength screw
amount of force with which the trigger is returned to its
rest position by the magnet. Turn the screw clockwise to
increase the amount of force. Do not turn the screw too far
or it will negate the position of the front stop trigger screw.
Turn the screw counter clockwise to reduce the amount
of force. Do not turn the screw too far or there will not be
enough force to return the trigger
22.
HarDWarE
, the
rear stop trigger screw
the micro switch activation screw
spring return strength screw.
is used to set the amount of
.
is used to set the amount of
is used to adjust the
(see fiGure 6.3).
menu (see
front
, the
magnet
(see
(see fiGure
fiG 6.1
fiG 6.2
fiG 6.3
