tHe eGo10 naViGation
console
At the rear of the Ego10 grip frame you will find the
navigation console
> turninG tHe eGo10 on and off usinG tHe
button
> scrollinG tHrouGH menus WitH tHe
and
> selectinG Parameters to edit usinG tHe
button
> editinG Parameters usinG tHe
buttons
> turninG tHe eGo10 breaK beam sensor
sYstem on and off usinG tHe
(PusH and Hold)
> resettinG recorded Values usinG tHe
button (PusH and Hold)
> controllinG tHe Game timer WitH tHe
button (QuicK PusH and release)
> scrollinG tHrouGH tHe Various run
screens usinG tHe
and release)
>disPlaYinG tHe current Preset loaded on
tHe eGo10 usinG tHe
and release)
WARNING
WarninG: tHe bacKliGHt on tHe lcd disPlaY
turns off after a Period of time. WHen tHis
HaPPens tHe marKer is still on and able to fire.
12. to adJust tHe lcd bacKliGHt see PaGe 43-44
(fiGure 1.5) which is used for:
buttons
button (QuicK PusH
button (QuicK PusH
PREVIOUS /
RAISE
SELECT
NEXT / LOWER
and
button
note: ThE COlOUr OF ThE bACKlighT ON ThE EgO10
lCD SCrEEN CAN bE ChANgED by ADjUSTiNg ThE rED,
blUE AND grEEN lEvEl PArAMETErS. SEE PAgE 43-44 FOr
fiG 1.5
FUrThEr DETAilS.
