PLANET ECLIPSE EGO TEN Operator's Manual page 13

oPerational oVerVieW
below is a brief overview of what happens during
the Ego10 firing cycle. The location of parts
discussed in the text below can be found on page
74-75.
Assuming the Ego10 is gassed up and turned on,
shows the marker in its idle position. The
fiGure 1.1
rammer is held in its rear position with pressurised
air from the lPr directed through the solenoid to
the front of the rammer. The valve chamber is full of
pressurised air from the inline regulator.
Providing a ball is in the breach, when the trigger
is pulled, a signal is sent to the solenoid which
redirects the supply of air from the front of the
rammer to the rear, which pushes the rammer and
bolt forward toward the valve
(fiGure 1.2).
happens the air in front of the rammer is vented out
through an exhaust port in the solenoid manifold.
The rammer makes contact with the valve stem
and continues to be pushed forward, now pushing
the valve forward with it. This breaks the valve seal
allowing pressurised air to flow up through the
valve and into the bolt and vent down the barrel,
propelling a ball.
(fiGure 1.3)
The time that the rammer is held in this forward
position is dependant on the
DWELL
The longer the dwell time the longer the Ego10
vents gas down the barrel. when this dwell time
has elapsed, the solenoid redirects the supply of air
from the back of the rammer to the front, pushing
the rammer and bolt back to the rear position. This
loss of forward force allows the valve to re-seal and
the valve chamber is re-pressurised. As the rammer
moves back air behind it is vented through an
exhaust port in the solenoid manifold
The Ego10 has now completed one cycle and is
ready to fire again.
As this
air supply
from solenoid
parameter.
air supply
from solenoid
(fiGure 1.4).
air venting
air supply
from solenoid
inline regulator
supply
air venting
inline regulator
supply
air venting
inline regulator
supply
air supply
from solenoid inline regulator
supply
