PLANET ECLIPSE EGO TEN Operator's Manual page 51

(continued)
Thoroughly clean the two 008 Nbr 70 o-rings on the
adjuster screw and lubricate ready for re-assembly. inspect
the top face of the adjuster unit for any excessive wear or
damage as this could cause the inline regulator to creep
(see fiGure 10.6).
note: ThE SEAliNg FACE ON ThE iNliNE rEgUlATOr
PiSTON CAN AlSO CAUSE ThE rEgUlATOr TO CrEEP Or
"SUPErChArgE", SO ThiS ShOUlD AlSO bE ChECKED.
with the threaded section towards to the base of the
regulator body, re-insert the adjuster screw into the
bottom half of the regulator body
Apply light pressure to the top of the adjuster screw and
using a 1/8" hex key wind the adjuster screw counter-
clockwise until it stops at the base of the regulator body.
Turn the adjuster screw 4 turns in a clockwise direction to
set the inline regulator pressure at approximately 160 psi.
Take the piston and spring and clean the seal at the top
of the piston, re-lubricating it with a light smear of Eclipse
grease ready for re-assembly (see fiGure 10.8).
piston and spring into the top half of the inline regulator
body
(see fiGure 10.9).
WARNING
WarninG: tHe sPrinG in tHe eGo10 inline
reGulator Has been desiGned sPecificallY for
tHe ecliPse eGo10. usinG anY otHer sPrinG Will
damaGe tHe eGo10 and Void Your WarrantY.
Keeping the top half of the inline regulator upside down,
screw the two halves of the inline regulator together
fiGure 10.10).
you have now stripped, cleaned, lubricated and assembled
your inline regulator.
note: iF ANy O-riNgS ArE DAMAgED ThEN rEPlACE
ThEM. ExTrA O-riNgS ArE AvAilAblE iN EgO10 PArTS
KiTS AvAilAblE ONliNE AT www.PlANETECliPSE.COM.
(see fiGure 10.7).
insert the
(see
WarninG: if You are at all unsure of PerforminG
Your nearest ecliPse serVice centre. (see PaGes
fiG 10.5
fiG 10.7
fiG 10.9
WARNING
tHe maintenance Procedure Please contact
72-73)
QuicK Guide
CONTENTS
ORIENTATION
QUICK SET-UP
USING YOUR EGO10
MENU TREE
ADVANCED SET-UP
MAINTENANCE MAINTENANCE
FAULT FINDING
SERVICE CENTERS
fiG 10.6
PARTS LIST
SPARES & ACCESSORIES
INDEX
fiG 10.8
fiG 10.10
51.
