PLANET ECLIPSE EGO TEN Operator's Manual page 37

fire mode
tHe firinG mode Parameter
This parameter is used to select the firing
mode of the Ego10 and has the following
choices:
> semi: This is the default and in this firing
mode the Ego10 will fire one shot for every
trigger pull.
> ramP**: in this firing mode, the rate of fire is increased
above the rate at which the trigger is pulled once certain
criteria have been met. These criteria are set by the
parameters on the
raMp SEtUp
> cancel: Editing is cancelled and the parameter is
unchanged.
** note: SOME PrESETS AND FirE MODES MAy ONly
bE AvAilAblE iN CErTAiN COUNTriES AND ON SOME
MODElS OF ThE EgO10.
rof caP
tHe rate of fire caP Parameter
The parameter is used to specify
rOF Cap
whether or not the Ego10 should have a
limited, or capped rate of fire. when the
is enabled, the maximum achievable
Cap
rate of fire is set by the
BS On rOF
Choices for the parameter are:
rOF Cap
> off: rate of fire only limited by the loader.
> on: rate of fire limited to the
parameter value.
> cancel: Cancel editing and leave the parameter
unchanged.
menu.
rOF
parameter.
BS On rOF
bs on rof
tHe maXimum rate of fire
Parameter
The parameter is used to set the
BS On rOF
maximum achievable rate of fire from the
Ego10. The value of this parameter can be
adjusted between 4.0 and 30.0 balls per
second in 0.1bps increments.
The parameter will only be
BS On rOF
displayed if you have set the
rOF Cap
parameter to 'ON' .
bs off rof
tHe rate of fire WHen bbss is off
Parameter
The parameter is used to control
BS OFF rOF
how fast the Ego10 cycles when the break
beam Sensor System is disabled. This
parameter can be set between 4.0 and 15.0
balls per second and should always be set
to the slowest speed of the loading system
in use.
note: AlwAyS CAlibrATE yOUr EgO10 rOF CAP
PArAMETErS TO ThE lOCAl FiElD bPS METEr AS
rEADiNgS MAy vAry FrOM METEr TO METEr.
