PLANET ECLIPSE EGO TEN Operator's Manual page 7

ecliPse sHaft 3 barrel
note: ThE bOrE SizE OF yOUr ShAFT 3 MAy vAry
ACCOrDiNg TO ThE MODEl OF EgO10 yOU hAvE.
your Eclipse Ego10 comes as standard with an Eclipse Shaft 3 barrel.
The barrel screws into the body of the Ego10 using a right hand thread
meaning that if you hold the Ego10 pointing away from you the barrel
screws into the body in a counter-clockwise direction.
The barrel comprises of two parts, a barrel back
The two parts are joined together with a left hand thread meaning that
if you hold the barrel, with the back nearest you, the front unscrews in a
counter-clockwise direction. The bore size of the barrel back is engraved
c
at the end of the barrel back .
On the barrel back there is a 016 Nbr 70 o-ring
barrel from vibrating loose from the Ego10 body when the marker is
fired. There is also a 015 Nbr 70 o-ring on the barrel front
alignment when the two sections are screwed together.
replace and lubricate these o-rings with Eclipse grease as necessary.
c
a
and a barrel front .
d
which prevents the
e
helps with
a
d
b
note: ThE EgO10 will ONly ACCEPT cocKer tHreaded
bArrElS. DO NOT USE ANy OThEr TyPE OF bArrEl ThrEAD.
b
e
