PLANET ECLIPSE EGO TEN Operator's Manual page 48

cleaninG tHe breaK
beam sensor sYstem
WARNING
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs
to maKe tHe marKer easier and safer to WorK
Undo the retaining screw for the break beam sensor cover
on the left hand side of the Ego10 using a 5/64" (2mm) hex
key
(see fiGure 9.1).
remove the sensor cover to expose the back of the break
beam sensor unit
carefully remove any debris, paint or moisture from the back
of the sensor unit and from inside the sensor cover.
lift the bbSS free from the Ego10 body and using another
dry cotton bud, remove any grease or debris build-up from
the front of the sensor unit
48.
on.
Using a dry cotton bud,
(see fiGure 9.2).
.
(see fiGure 9.3)
fiG 9.1
fiG 9.2
fiG 9.3
