PLANET ECLIPSE EGO TEN Operator's Manual page 63

remoVinG tHe ValVe
assemblY
WARNING
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs
to maKe tHe marKer easier and safer to WorK
on.
lift the bolt pin and slide the bolt out of the rear of the
marker. Disconnect any hosing and unscrew the inline
regulator from the front regulator mount as detailed in the
Cleaning the inline regulator section of this maintenance
guide (page 50-51). remove the frame as detailed on page
57.
Take the Ego10 body and turn it so that the underside
of the solenoid assembly, and valve plug are visible and
accessible (see fiGure 17.1) . Using a 1/8" hex key remove
the screw from the front regulator mount that holds the
lPr body into the marker body
remove the entire lPr assembly, the valve spring and
the exhaust valve from the marker body
. Using a 1/8" hex key remove the valve plug from
17.3)
the underside of the Ego10 body
bottom of the exhaust valve guide should now be visible
through the valve plug hole
(see fiGure 17.5)
the rammer is in its rear position and taking an l-shaped
hex key, place it down through the bolt slot in the top of
the body so that you can apply light pressure to pop the
valve guide out of its place in the Ego10 body
17.6) .
WARNING
WarninG: if You are at all unsure of PerforminG
tHe maintenance Procedure Please contact
Your nearest ecliPse serVice centre. (see PaGes
72-73)
(see fiGure 17.2) .
(see fiGure
. The
(see fiGure 17.4)
. Ensure that
(see fiGure
fiG 17.1 fiG 17.2
fiG 17.3 fiG 17.4
fiG 17.5
fiG 17.6
