PLANET ECLIPSE EGO TEN Operator's Manual page 43

triGGer
tHe triGGer detection
Parameter
The Ego10 is fitted with a dual trigger pull
detection system. A non-contact Opto-
electronic trigger sensor arrangement is
used to detect trigger movement whilst
a micro - switch is used to provide a more
traditional tactile feedback for the trigger.
The parameter is used to select
triggEr
which system is used. The choices available
are as follows:
> oPto: Select the Opto sensor for trigger pull detection.
> sWitcH: Select the micro-switch for trigger pull
detection.
> cancel: Cancel editing and leave the parameter
unchanged.
sound
tHe sound Parameter
The Ego10 board is capable of emitting a
variety of sounds to audibly signal when
certain functions have been performed,
including, but not limited to, powering up,
powering off, changing the bbSS mode
and resetting various counters and timers.
This parameter determines if this feature is
switched on or off, switching it on will cause
more drain on the battery. The choices
available for this parameter are:
>off: Sounds switched off.
Sounds switched on.
>on:
>cancel: Cancel editing and leave the parameter
unchanged.
tones
tHe tones Parameter
This parameter determines if the Ego10
emits a tone each time any of the
pushbuttons on the navigation console
are activated. As part of the smart menu
system the parameter will only be
tOnES
shown in the menu if the
HarDWarE
parameter is switched 'ON' . The choices
available for this parameter are:
>off: Tones switched off.
>on: Tones switched on.
> cancel: Cancel editing and leave the parameter
bacKliGHt
tHe lcd bacKliGHt time
Parameter
The time the lCD backlight remains on after
a pushbutton is pushed. The parameter can
be set between 0 and 20 seconds.
if the time is set to 00:00 then the light will
not be displayed.
red leVel
tHe lcd bacKliGHt red leVel
Parameter
The percentage of red light emitted from
the lCD backlight.
