PLANET ECLIPSE EGO TEN Operator's Manual page 52

cleaninG tHe loW
Pressure reGulator
(lPr)
WARNING
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs
to maKe tHe marKer easier and safer to WorK
note: ThE iNTErNAlS OF yOUr lPr MAy vAry
ACCOrDiNg TO ThE MODEl OF EgO10 yOU hAvE.
The inline regulator can be removed if needs be.
Unscrew the lPr cap from the marker body
(see fiGure 11.1).
remove the lPr piston and rear spring from the lPr cap
(see fiGure 11.2).
Cupping the palm of one hand, turn the lPr cap upside
down and tip the front spring out into your palm
fiGure 11.3).
remove the rear spring from the lPr piston and using a
dry cotton bud, carefully clean the 013 Nbr 70 o-ring on
the lPr piston
then replace it. Once the seal has been cleaned, lubricate
with a light application of Eclipse grease so that it is ready
for re-assembly.
note: ThE ADjUSTEr SCrEw DOES NOT NEED TO
bE rEMOvED FrOM ThE lPr CAP FOr rEgUlAr
52.
on.
if the seal is damaged
(see fiGure 11.4).
MAiNTENANCE.
(see
fiG 11.1
fiG 11.2
fiG 11.3
fiG 11.4
