PLANET ECLIPSE EGO TEN Operator's Manual page 71

sYmPtom
The break beam sensor system does not
appear to be reading correctly.
The break beam sensor system is not
reading at all.
Two or more balls are being fed into the
breech.
Ego10 is inconsistent.
leaking rammer assembly ( leak gets
louder when bolt is removed ).
Eye turns itself off after firing.
when the Ego10 powers up, no game timer
/ shot counter / rOF indicator is displayed
and the gun will not fire.
The Ego10 leaks out of the lPr body vent
hole (small hole below the lPr assembly on
the Ego10 body).
Possible cause
The break beam sensor system is dirty.
break beam sensors are the wrong way around.
There is a broken wire or contact, or a short
circuit on either of the breech sensor cables.
Either sensor is back to front.
if the Ego10 is being used with a force feed
loader, it is possible that the loader is forcing
balls past the ball detent.
inline regulator is supercharging.
Front rammer shaft seal deteriorated.
Eye is dirty.
Eye is faulty.
Eye is out of place.
The trigger is permanently depressed.
The two rear 14x2 o-rings on the lPr body are
damaged.
solution
Keep the break beam sensors clean to ensure
correct readings (See Maintenance Section).
Check that the red receiver is on the right-hand
side of the breech.
Check the plug of the cables.
Check for cuts or pinches in the sensor cables.
Check that the sensors face each other when
installed.
Change the rubber finger detent.
Strip and clean inline regulator.
(See Maintenance section )
replace front rammer shaft seal.
Clean the eyes.
replace the eyes.
re-install Eyes. Check alignment.
Turn the front stop set screw in the top of the
trigger counter-clockwise until the display
reads correctly. if there is sufficient trigger
adjustment then turn the return force set screw
counter clockwise also.
replace both rear o-rings with new 14x2
Nbr70 o-rings.
