tHe sound indicator
The sound indicator on the run screen is used to convey if
the parameter in the
SOUnD HarDWarE
switched on or off.
There are two possible conditions that can be indicated:
sound enabled
The parameter is enabled. The Ego10
SOUnD
will make sounds when switched on and off
and when the game timer alarms or times out.
sound disabled
The parameter is disabled. The Ego10
SOUnD
will not make any sounds.
tHe triGGer detection
indicator (tdi)
in order for the trigger to be successfully operated it must
first be released and then pulled. The trigger detection
indicator (TDi) is used to indicate each of the possible
trigger states.
oPto sensor selected, readinG 0%
The Ego10 is configured to use the Opto
sensor to detect trigger pulls. The Opto sensor
is currently reading 0%, i.e. the trigger is fully
released.
oPto sensor selected, readinG
beloW release Point
The Ego10 is configured to use the Opto
sensor to detect trigger pulls. The Opto sensor
is currently reading below the Opto release
point, i.e. the trigger is considered 'released' .
menu (page 43) is
From the factory the Ego10 will have the Opto sensor
enabled. The micro-switch option can be selected by
referring to the
oPto sensor selected, readinG
mid-ranGe
The Ego10 is configured to use the Opto
sensor to detect trigger pulls. The Opto sensor
is currently reading somewhere between the
Opto release point and the Opto pull point, i.e.
the trigger is half depressed.
oPto sensor selected, readinG
aboVe Pull Point
The Ego10 is configured to use the Opto
sensor to detect trigger pulls. The Opto sensor
is currently reading above the Opto pull point,
i.e. the trigger is considered 'pulled' .
oPto sensor selected, readinG
100%
The Ego10 is configured to use the Opto
sensor to detect trigger pulls. The Opto sensor
is currently reading 100%, i.e. the trigger is
fully depressed.
micro-sWitcH selected, not
actuated
The Ego10 is configured to use the micro-
switch to detect trigger pulls. The micro-switch
is not currently actuated, i.e. the trigger is
released.
micro-sWitcH selected, actuated
The Ego10 is configured to use the micro-
switch to detect trigger pulls. The micro-switch
is currently actuated, i.e. the trigger is pulled.
HarDWarE menu (see page 43).
