PLANET ECLIPSE EGO TEN Operator's Manual page 17

usinG tHe breaK beam
sensor sYstem
The break beam sensor system, referred elsewhere in this
manual as 'bbSS' is used to detect when a paintball is ready
to fire from the Ego10. if no paintball is ready then the
bbSS will inhibit the Ego10 from firing. This prevents the
Ego10 from 'chopping' paintballs that are not fully loaded
into the marker.
To switch off the bbSS, press and hold the
seconds (see fiGure 3.3).
The bbSS indicator on the top right of the lCD will change
from (enabled) to (disabled).
To switch the back on, press and hold the
BBSS
for 0.5 second. The indicator will change back to
when the bbSS is enabled, the indicator will change
depending on if the system has detected a ball or not.
when no ball has been detected the indicator looks like
this when a ball has been detected the icon changes to
look like this .
Additional features of the Ego10's break beam sensor
system are covered in full on page 26 of this user manual.
note: whEN ThE EgO10 iS TUrNED ON, ThE brEAK bEAM
SENSOr SySTEM iS AUTOMATiCAlly ENAblED.
button for 0.5
button
.
