PLANET ECLIPSE EGO TEN Operator's Manual page 18

settinG uP Your eGo10
before you can begin to use your Ego10, you will need to
attach an air system and a paintball loader.
installinG a Preset air
sYstem
Every Ego10 comes complete with an Eclipse On/Off
Purge System (OOPS) which provides a direct connection
for a preset air system. before screwing the air system
into the OOPS ensure that the On/Off knob is wound out
approximately half way
unscrew the On/Off knob too far as it will come completely
off the OOPS. if this happens, replace the On/Off knob
by screwing it back onto the OOPS body in a clockwise
direction.
Screw the preset air system into the OOPS
4.2) so that the bottle screws in all the way and is tight.
Slowly turn the On/Off knob in a clockwise direction
allowing the OOPS to depress the pin of the preset
air system causing the Ego10 to become pressurised,
providing that there is sufficient air in your tank
fiGure 4.3).
you have now installed a preset air system onto your
Ego10.
WARNING
WarninG: tHe eGo10 cannot be used WitH co2,
it can onlY be PoWered bY comPressed air or
note: wE rECOMMEND USiNg A PrESET Air SySTEM
wiTh A high PrESSUrE OUTPUT TO AChiEvE OPTiMUM
PErFOrMANCE FrOM ThE EgO10, hOwEvEr MOST gOOD
qUAliTy lOw PrESSUrE OUTPUT SySTEMS will AlSO
WARNING
WarninG: alWaYs relieVe all residual Gas
Pressure from tHe eGo10 before unscreWinG
18.
(see fiGure 4.1). be careful not to
(see fiGure
nitroGen.
wOrK ON ThE EgO10.
tHe Preset air sYstem.
WARNING
WarninG: maKe sure tHe marKer is turned off
and tHat no Paintballs are in tHe marKer or
loader before installinG an air sYstem.
(see
fiG 4.1
fiG 4.2
fiG 4.3
