attacHinG tHe frame
WARNING
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs
to maKe tHe marKer easier and safer to WorK
Carefully thread the solenoid and break beam sensor
system wires through the access holes in the top of the
Ego10 grip frame
frame to the marker body by tightening the two grip frame
screws using a 1/8" hex key
Ensure that the break beam sensor system cables lie neatly
in the slots provided for them in the Ego10 grip frame
and connect the solenoid and the break beam sensors
to their relevant connections on the Ego10 circuit board
(see fiGure 14.7)
the break beam sensor system wires so that they sit neatly
within the grip frame
re-attach the Ego10 rubber grips to the frame by using a
5/64" hex key to replace the 6 grip screws.
58.
on.
and re-attach the grip
(see fiGure 14.5)
.
(see fiGure 14.6)
. Adjust both the solenoid wires and
.
(see fiGure 14.8)
fiG 14.5
fiG 14.6
fiG 14.7
fiG 14.8
